Digital Multimeter advanced EEDM596F by Snap-on, USA

Description

Features of Digital Multimeter advanced EEDM596F by Snap-on, USA

• Use in the following six quick steps: get the app, select unit of measure, connect leads to circuit, sync to remote device, take readings then diagnose, store and share results (mobile device sold separately)

• Horizontal orientation is comfortable for button and dial operation

• 115% larger color display for excellent viewing

• Bluetooth® remote display allows for one-tech testing, such as brake lights (mobile device sold separately)

• Stores customer information and test results, with the ability to share via email, text or social media (mobile device sold separately)

• CAT-III 1,000 V / CAT-IV 600 V hybrid safety rated

• Convenient test lead storage wrap with retention strap

• Built-in tilt stand and optional strap hanger (EEDMMAGSTRAP) for easy viewing

• LCD display: 40,000 count with 42-segment bar graph

• REC: Record mode stores minimum, maximum and average readings over a measurement period

• RANGE: manually select range or allow auto-ranging

• FUNCTION: toggle between functions on Ohm, TEMP and IG modes

• REL (Relative Mode): factor out lead resistance for improved low ohm measurements or compare readings to a known standard—can also be used for differential measurements

• CYL (Cylinder): selects the number of cylinders in IG mode

• HOLD: lock the reading on the display for hard to read locations or future reference

• PEAK-H (Peak Hold): capture signals spikes as fast as one millisecond to diagnose intermittent events

• Hz (Frequency): measure the frequency of sensors and signals

• AC mV and DC mV Ranges: additional 40 millivolt DC range with 0.01 mV resolution for improved accuracy when performing low voltage measurements

• DC V, AC V (DC Volts, AC Volts): measure the voltage of circuits, sensors and ABS wheel sensors

• TEMP (Temperature): measure temperature with included temperature probe

• AC/DC Current Functions: measure the parasitic draw from the battery

• IP, IG (Automotive Functions): measure RPM, Duty, Dwell, mS pulse width, Frequency

• AC/DC: manually select AC or DC measurement function

• Quickly Test Condition of Internal Fuses: determine the status of the internal fuses before you open the battery/fuse compartment

• Built-in Tilt Stand: tilt stand is built into the instrument housing, adding strength and integrity to the design
